Catatan :
– Berlaku untuk area Jawa Tengah & DIY
– Harga tidak mengikat, sewaktu waktu dapat berubah
– Tidak termasuk karoseri dan KIR
SPESIFIKASI KENDARAAN
KEMAMPUAN
| Kecepatan Maksimum | km/jam | 126 |
| Daya tanjak | tan | 31,7 |
MESIN
| Model | W04DTP | |
| Type | Mesin Diesel 4 Langkah Segaris; Direct Injection; Turbo Charge Intercooler | |
| Jumlah Silinder | 4 | |
| Kapasitas Silinder | Cc | 4.009 |
| Tenaga Maximum | PS/rpm | 110 / 2.800 |
| Torsi Maximum | Kg.m/rpm | 29/1.800 |
TRANSMISI
| Type | M153 | |
| Perbandingan Gigi | ||
| Gigi ke-1 | 5.339 | |
| Gigi ke-2 | 2.792 | |
| Gigi ke-3 | 1.593 | |
| Gigi ke-4 | 1.000 | |
| Gigi ke-5 | 0.788 | |
| Mundur | 5.339 |
KOPLING
| Type | Pelat Kering Tunggal; Hydraulic Operation | |
| Diameter Cakram | mm | 300 |
KEMUDI
| Type | Recirculating Ball Screw | |
| Minimal Radius Putar | m | 7.2 |
SUMBU
| Depan | Reverse Elliot, I-Section Beam | |
| Belakang | Full Floating Type, Single Reduction, Single Speed by Hypoid Gear | |
| Perbandingan Gigi akhir | 4.625 | |
REM
| Rem Utama | Vacuum Servo dengan Sirkuit Ganda; Dilengkapi Booster |
| Rem Parkir | Internal Expanding; Out Shaft Transmisi |
| Rem Pelambat | Dengan pipa gas buang |
RODA DAN BAN
| Ukuran Rim | 15 x 5.50F-30 |
| Ukuran Ban | 7.50-15-14 PR |
| Jumlah Ban | 4 (+1) |
SUSPENSI
| Depan & Belakang | Rigid axle dengan pegas daun semi elliptic |
TANKI
| Kapasitas | 100 Liter |
BERAT CHASIS
| Berat Kosong | Kg | 2.081 |
| GVWR / GCWR | Kg | 5.200 |
SISTEM LISTRIK ACCU
| Accu | 12V 100AH (Battery Tunggal) |
DIMENSI
| Jarak Sumbu Roda | mm | 3.405 |
| Total Panjang | mm | 6.430 |
| Total Lebar | mm | 1.720 |
| Total Tinggi | mm | 2.155 |
| Lebar Jejak Depan | mm | 1.415 |
| Lebar Jejak Belakang | mm | 1.420 |
| Julur Depan | mm | 1.065 |
| Julur Belakang | mm | 1.960 |
| Cabin to End | mm | 4.700 |
JENIS KAROSERI
| Box |  |
| Bak Terbuka |  |
| Loss Bak / Flat Bed |  |
| Box Pendingin |  |
